| HSP 015 | HSP 020 | HSP 025 | HSP 028 | HSP 035 | HSP 040 | HSP 050 | HSP 055 | |
|---|---|---|---|---|---|---|---|---|
| Maximum pressure (MPa) | 23 | 23 | 23 | 23 | 23 | 23 | 23 | 23 |
| Maximum load (kg) | 2.000 | 2.000 | 3.500 | 3.500 | 5.000 | 5.000 | 5.000 | 5.000 |
| Width (mm) | 355 | 355 | 434 | 434 | 472 | 472 | 472 | 472 |
| Height closed grapple (mm) | 510 | 510 | 540 | 530 | 565 | 610 | 615 | 695 |
| Height open grapple (mm) | 685 | 645 | 690 | 635 | 600 | 630 | 830 | 715 |
| Closed length (mm) | 740 | 780 | 800 | 830 | 885 | 970 | 1.080 | 1.110 |
| Maximum aperture (mm) | 1.170 | 1.400 | 1.450 | 1.690 | 1.880 | 2.070 | 2.110 | 2.390 |
| Weight (kg) | 120 | 130 | 225 | 230 | 255 | 285 | 310 | 325 |
HSP Gripen STANDARD
The twin cylinders of the Standard grapples provide low and uniform axle load, which results in less wear. The design of the grapples allows the wood rollers to roll smoothly, fill the grapples efficiently, and ensure that the load stays in place. It works quickly and easily on all types of material.
 |
David Magalhães
Sales department |
Description
Additional information
| Brand |
Hsp Gripen |
|---|
About brand
Forestcorte Máquinas, S.A is the representative of HSP Gripen, a Swedish brand that has the most complete line of grippers on the market, with more than 100 models, for difficult and heavy jobs. They manufacture the grapples completely by themselves, from the base to the finished product. Production is carried out through cutting procedures using lasers, robotic gas and plasma welding, automatic turning and multi-operation machining using state-of-the-art machines for efficient production, such as steel which is also of the highest quality. Stability is guaranteed using double boom tubes on almost all models (except models 015 and 020) and a well thought out design for any job.
