HSP 015 HD | HSP 020 HD | HSP 025 HD | HSP 028 HD | HSP 035 HD | HSP 040 HD | HSP 050 HD | HSP 055 HD | |
---|---|---|---|---|---|---|---|---|
Maximum pressure (MPa) | 23 | 23 | 23 | 23 | 23 | 23 | 23 | 23 |
Maximum load (kg) | 2.000 | 2.000 | 3.500 | 3.500 | 5.000 | 5.000 | 5.000 | 5.000 |
Width (mm) | 355 | 355 | 434 | 434 | 472 | 472 | 472 | 472 |
Height open grapple (mm) | 685 | 645 | 690 | 635 | 600 | 630 | 830 | 715 |
Height closed grapple (mm) | 510 | 510 | 540 | 530 | 565 | 610 | 615 | 695 |
Closed length (mm) | 740 | 780 | 800 | 830 | 885 | 970 | 1.080 | 1.110 |
Maximum aperture (mm) | 1.170 | 1.400 | 1.450 | 1.690 | 1.880 | 2.070 | 2.110 | 2.390 |
Weight (kg) | 150 | 160 | 250 | 260 | 285 | 320 | 340 | 365 |
HSP Gripen Heavy Duty (HD)
The grapples of the Heavy Duty model are more powerful and more rigid: thicker steel plates, larger rotator plate, reinforced lower boom tubes. They are designed for heavy-duty and difficult work and are particularly suitable for forwarders.
![]() |
David Magalhães
Sales department |
Brand |
Hsp Gripen |
---|

Forestcorte Máquinas, S.A is the representative of HSP Gripen, a Swedish brand that has the most complete line of grippers on the market, with more than 100 models, for difficult and heavy jobs. They manufacture the grapples completely by themselves, from the base to the finished product. Production is carried out through cutting procedures using lasers, robotic gas and plasma welding, automatic turning and multi-operation machining using state-of-the-art machines for efficient production, such as steel which is also of the highest quality. Stability is guaranteed using double boom tubes on almost all models (except models 015 and 020) and a well thought out design for any job.
